Despite fuel cells are an old technology, in automotive application they have a short history. Since approximately 20 years car manufacturer tried to implement fuel cells into vehicles like passenger cars, heavy and light duty trucks or caravans. To date there are three different ways of implementation for fuel cells into ground vehicles. It can be used as main drive, range extender or auxiliary power unit.
Index of contents
1 Introduction
2 Basics
3 Fuel cells in automotive application
3.1 Fuel cells as main drive
3.2 Fuel Cells as range extender
3.3 Fuel cells as Auxiliary Power Unit (APU)
4 Problems of fuel cells
4.1 Storage of hydrogen
4.2 Hydrogen infrastructure
4.3 Exhaustible raw materials dependence
5 Conclusion
6 References
1 Introduction
In the last 20 years, the automotive industry had to adopt itself to the rapidly changing market. Environmental awareness gets more and more important in the western but also in the emerging countries. Due to the global warming governments all over the world enact laws to protect the environment. The European Union (EU) for example limited the emission of CO2 from 2015 to 120 g/km and from 2020 even to 95 g/km for each new car that is licensed in the EU.1
Particularly air pollution in China’s cities is extremely high. 20 of the 30 cities with worldwide highest pollution are located in China. Not only industry but also individual transportation grows extremely year by year. China’s government enacted emission standards for vehicles according to European model in several cities like the capital Beijing or Shanghai. Despite big efforts to advance air quality, there is no significant improvement because of 1.300 new registered vehicles daily.2
Due to the different ecological laws, car manufacturers spend big efforts in developing fuel saving technology and alternative drives. On the one hand, systems like direct fuel injection, engine start-stop, that turns off the engine while idling, or intelligent energy control are just some examples for reducing fuel consumption in commercial vehicles. Toyota on the other hand released their Prius on Japanese market in 1997 which was the first commercial available hybrid car. Especially in Germany many car manufacturers realized their failure in this technology and now spend big efforts in development of hybrid cars.
To reduce emission of greenhouse gases, there is another key technology which is actually very old but because of the development of combustion engine it was buried in oblivion. DaimlerChrysler with the NECAR 1 proved that Fuel Cells generally can be implemented in cars to provide the needed electrical energy for propulsion. Nowadays many companies try to push this technology forward, but 15 years later there is still no commercial car available which is equipped with a fuel cell. The following pages give a short overview of fuel cells, implementation of them into individual mobility and problems companies have to face.
2 Basics
A fuel cell converts chemical energy directly, which means without a thermal expansion process, into electricity. In principle such a cell works with a reduction and oxidation element. Both have to be continuously supplied to the fuel cell, unlike a battery or accumulator fuel cells stay unchanged. A fuel cell consists of two electrodes sandwiched around an electrolyte, which assure that both gases do not contact and due to that not react. Encouraged by catalyst hydrogen atoms split into a proton and an electron, which take different paths to the cathode.
illustration not visible in this excerpt
Only the resulted proton can cross the electrolyte, while electrons create a separate current that can be utilized before reaching the cathode, to be reunited with hydrogen and oxygen in a molecule of water. At the cathode the following reaction proceeds:
illustration not visible in this excerpt
Figure 1 shows the electrochemical process of a fuel cell in principle.
illustration not visible in this excerpt
Figure 1: Configuration of a PEMFC[3]
A fuel cell system which includes a "fuel reformer" can utilize the hydrogen from any hydrocarbon fuel - from natural gas to methanol, and even gasoline. Since the fuel cell relies on chemistry and not combustion, emissions from this type of a system would still be much smaller than emissions from the cleanest fuel combustion processes.[4]
Frequently asked questions
What is the main focus of this document?
This document provides a comprehensive language preview, including the title, table of contents, objectives, key themes, chapter summaries, and keywords related to fuel cells and their automotive applications.
What topics are covered in the table of contents?
The table of contents includes sections on the introduction to fuel cells, basic fuel cell principles, fuel cell applications in the automotive industry (as a main drive, range extender, and auxiliary power unit), problems associated with fuel cells (hydrogen storage, infrastructure, and raw material dependence), a conclusion, and references.
What is the context given in the Introduction?
The introduction highlights the increasing environmental awareness and stricter emission regulations in the automotive industry. It mentions the EU's CO2 emission limits for new cars and the air pollution issues in China, leading car manufacturers to develop fuel-saving technologies and alternative drives, including fuel cells.
How does a fuel cell work?
A fuel cell converts chemical energy directly into electricity through a reduction and oxidation process. It consists of two electrodes separated by an electrolyte. Hydrogen atoms are split into protons and electrons, with the protons crossing the electrolyte and the electrons creating a current that can be utilized. These components then recombine with oxygen to form water.
What are some key challenges mentioned regarding fuel cell technology?
Some key challenges include the storage of hydrogen, the development of a sufficient hydrogen infrastructure, and the dependence on potentially exhaustible raw materials.
What is the document's objective?
The document aims to provide a short overview of fuel cells, their implementation in individual mobility, and the problems companies face in advancing this technology.
What types of fuel cells are discussed in this document?
While the document provides a general overview, it mentions that fuel cells are classified based on their electrolyte material and working temperature, which also dictates their application area. Tables (not included in this excerpt) would list and classify different types of fuel cells.
